Applications:
Volume KTV rooms
Clubs
Conference rooms
Classrooms
Features:
Reasonable and accurate crossover design effectively balances the different characteristics of each speaker unit, achieving frequency balance. The auditory experience is harmonious, the sound image is accurate, the sense of music is clear, the layers are distinct, and the sound quality effect is comfortable. The low frequency is full and elastic, and the mid-to-high frequency is delicate and wide, with a natural and sweet sound. The streamlined mask and the enclosure are closely integrated, showing noble and atmospheric style, and are seamlessly integrated. There is an M8 hanging point on the top, suitable for various hanging places.
Specifications:
Electrical Performance Parameters
Frequency Response: 50Hz - 20KHz
Sound Pressure Sensitivity (1W/1M): 91 dB SPL
Maximum Continuous Sound Pressure Level: 116 dB SPL
Peak Sound Pressure Level: 119 dB SPL
Input Impedance: 8 Ω
Coverage Angle (H×V) -6dB: Horizontal: 110° Vertical: 90°
Rated Output Power: 200W
Peak Output Power: 400W
Low Frequency: 1× 10-inch precision low-frequency transducer
High Frequency: 4× 3-inch paper cone high-frequency drivers
Low Frequency Magnet Diameter: 50mm
High Frequency Magnet Diameter: 14mm
Enclosure: Internally reinforced 12mm thick environmentally friendly medium-density fiberboard
Dimensions (Width×Depth×Height): 520mm×285mm×315mm
Weight: Net Weight: 10 kg (per unit) / Gross Weight: 21.5 kg (per pair)
